For the introduction of lpg gasoline forklift, some customers know how or where they have heard it. I believe everyone is familiar with diesel forklifts. If you have a certain understanding of diesel forklifts, it will be easier to learn about lpg forklift gas.
Brand:
HIFOUNEItem No.:
FG30Product origin:
Xiamen, ChinaColor:
White, Orange, RedShipping port:
Xiamen PortLead Time:
7 DaysIn fact, for the introduction of lpg gasoline forklift, some customers know how or where they have heard it. I believe everyone is familiar with diesel forklifts. If you have a certain understanding of diesel forklifts, it will be easier to learn about lpg forklift gas.
In appearance, lforklift gas fittings are not particularly different from diesel forklifts. The main difference is that one or two more bottles of liquefied petroleum gas are added to the top of the counterweight of the LPG forklift to store fuel. The fuel installed above is used to provide the power required by the forklift when working. In this regard, according to different forklift models and different counterweight tonnages, we will reasonably design and recommend more reasonable LPG forklifts to customers according to their needs. For example, it is four wheel lpg forklift or six wheel forklift lpg system. The specifics are determined by the needs of our customers.
Hifoune Lpg Forklift Truck Specification
| Manufacturer | Xiamen Hifoune Machinery Co.,Ltd | |||||
| Model | FG20 | FG25 | FG30 | FG35 | FG40 | |
| Fuel | LPG&Gasoline | |||||
| Operator Type | Driver/seat | |||||
| Load Capacity | kg | 2000 | 2500 | 3000 | 3500 | 4000 |
| Load Center | mm | 500 | ||||
| Max.Lifting Height | mm | 3000 | ||||
| Free lifting height | mm | 150 | ||||
| Fork Size L*W*T | mm | 1220*122*40 | 1220*125*45 | 1220*125*50 | ||
| Mast Tilting Angle Fwd/Bwd | deg | 6/12 | ||||
| Overall Length (without fork) | mm | 2605 | 2705 | 2760 | 2820 | |
| Overall Width | mm | 1150 | 1240 | 1300 | ||
| Mast Height(Fork Lowered) | mm | 2040 | 2140 | |||
| Overhead Guard Height | mm | 2090 | 2100 | |||
| Turning raduis (exterior) | mm | 2170 | 2240 | 2400 | 2560 | |
| Min.right angle stacking aisle width | mm | 2010 | 2230 | 2330 | 2360 | 2480 |
| Travelling Speed (Loaded/Unloaded) | km/h | 17/19 | 19/20 | |||
| Lifting Speed (Loaded/Unloaded) | mm/s | 650/710 | 630/690 | |||
| Lowering Speed (Loaded/Unloaded) | mm/s | 480/450 | ||||
| Max.drawbar pull (Loaded) | N | 18 | ||||
| Max.Gradability(Loaded) | % | 21 | ||||
| Service brake (Operation/Control) | Hydraulic-foot pedal | |||||
| Parking brake (Operation/Control) | Mechanical-hand lever | |||||
| Battery (voltage/capacity) | V/ah | 12/80 | ||||
| Truck Weight | kg | 3590 | 3810 | 4110 | 4410 | 4800 |
| Weight distribution Loaded (Front/Rear) | kg | 4920/670 | 5615/695 | 6256/854 | 7040/870 | 7832/968 |
| Weight distribution Unloaded (Front/Rear) | kg | 1615/1975 | 1715/2095 | 1850/2260 | 1985/2425 | 2160/2640 |
| Tyre | Pneumatic Tire | |||||
| Tyre Size (Front/Rear) | 7.00-12-12PR/6.00-9-10PR | 28*9-15-14PR/6.50- | 0-10PR |
250-15-16PR 6.50-10-14PR |
||
| Tyre Number (Front/Rear) | 2/2 | |||||
| Front tread | mm | 970 | 1000 | |||
| Rear tread | mm | 970 | ||||
| Engine model | KUBOTA WG2503-GL-E3 | |||||
| Rated power | KW/rpm | 46.0/2700 | ||||
| Rated torque | N-m/rpm | 178.0/1400 | ||||
| Number of cylinder | 4 | |||||
| Displacement | L | 2.491 | ||||
| Emission Standards | EURO Stage 5 | |||||
| Fuel tank capacity | L | 70 | ||||
| Transmission box type | Electronic hydraulic transmisson | |||||
